Components  Required:
1 each of Weeding Blades S100 and S101 (#'s on cast arms between the rivets)
2 of  3/8”x1-1/4” square head bolts + flat washers, lock washers and 3/8” nuts
Position the weeding blades as shown below for various widths of cut. Move the front wheel up or down to make the blades nearly
parallel to the ground. Select a cutting width that is narrow enough to let you push the wheel hoe at a steady pace.

When weeding wide paths, select a width just over half of the path width and make two passes to weed each pathway.
Weeding Blade (Sweeps) Assembly
  • Weed large open garden areas that have not yet been planted (seedbeds)
  • Weed the garden paths between beds or rows of plants
  • Weed right next to rows of seedlings or plants. (one side at a time, or both sides at once)
Path or Seedbed Weeding Options:
Wheel hoe weeding options
Wheel hoe set up as garden cultivator
Wheel Hoe set for path weeding
